WISENT BÜFFEL BISON Working method Haulm cutting + chopping
above the damHaulm cutting
in the damHaulm cutting in the dam,
subsequent choppingTractor attachment Front attachment Front and rear attachment Front attachment Drive Gear drive Hydraulic system Hydraulic system PTO shaft + + + Cutting device 24 x hammer mallet 2 x blade disc 2 x blade disc + mulching
unit with 40 blades/counter-bladesSupport wheel for depth control 2 2 2 Support wheel height adjustment Hydraulic Manuel via crank or hole pattern Hydraulic Side crop lifter 2 - 2 Camera - - 2 Hydraulic feed to the mulching unit - - + Ploughshare body for cleaning the blade disc - 2 - Dimensions in mm approx. 1350 x 2200 x 1200 1500 x 2285 x 1520 2775 x 2500 x 2250 Max. speed in rpm approx. 3000 3000 3000 Power requirement in hp approx. ≥ 70 - 80 ≥ 70 - 80 ≥ 160 Weight in kg approx. 750 630 1800 -
Function / Application:
- for cutting and shredding asparagus haulm in the dam before winter
- for the mechanical control of
a) asparagus fly
b) asparagus rust (fungal infestation)
- Front attachment
- PTO shaft
- 2 x hydraulically operated blade disc for cutting the asparagus in the dam
- Internal hydraulic system for operating the blade discs
- 2 x Infinitely adjustable support wheel for depth control
- Hydraulically operated feeding device to the mulching unit
- Mulching unit with 40 blades and counter blades
- 2 x Camera for monitoring the feeding and cutting device
- 2 x Side crop lifter
- 2 x Support foot
- Mulcher shaft speed: approx. 3.000 rpm (Drive via PTO)
- Row distance: from approx. 1900 mm
- Power requirement: min. approx.160 hp
- Tractor requirements:
- Front PTO
- Double-acting (DW) control unit in the front
- Permanent 60 l/min volume flow
- Dimensons LxWxH: approx. 2775 x 2500 x 2250 mm
- Weight: 1800 kg
- Asparagus haulm is cut off above the crown and then shredded completely into small pieces.
= faster decay of the plant residues
= better dam hygiene
Individual modifications regarding equipment, dimensions, etc. are possible on request.
